Commercial Pilot ACS Study Guide: Systems and Equipment Malfunctions
A systems or equipment malfunction does not always announce itself as an obvious emergency. Sometimes the first indication is a warning light, abnormal gauge reading, unusual sound, failed instrument, or piece of equipment that simply stops working.
At the commercial pilot level, the goal is to recognize the malfunction, understand its effect on the flight, apply the correct procedure, and make an appropriate decision before the situation becomes more serious.
Know Your Aircraft Systems
Effective troubleshooting starts with understanding how the aircraft normally operates.
A commercial pilot should be familiar with systems applicable to the aircraft, including:
- Engine and propeller
- Fuel
- Electrical
- Pitot-static
- Vacuum or pressure systems, if equipped
- Flight instruments
- Landing gear
- Flaps
- Avionics and navigation equipment
- Heating and ventilation
- Autopilot and other installed equipment
You should be able to explain not only what a system does, but what indications you would expect if part of that system failed.
Recognize the Malfunction
Abnormal indications should be investigated rather than immediately accepted as a complete system failure.
For example, an unusual indication could result from:
- An actual system malfunction
- Failed sensor or gauge
- Electrical problem
- Blocked pitot or static source
- Improper switch or control position
- Circuit protection issue
Compare the indication with other available information.
If the ammeter shows an abnormal electrical condition, what else can you verify? If an airspeed indicator becomes unreliable, do the altimeter and vertical speed indicator provide additional clues?
Use all available information before deciding what has failed.
Electrical System Malfunctions
Electrical failures can range from the loss of a single component to the gradual depletion of the aircraft battery.
Possible indications include:
- Low-voltage warning
- Abnormal ammeter or loadmeter indication
- Alternator or generator warning
- Dimming lights
- Intermittent avionics
- Multiple electrical components failing
Follow the aircraft’s POH/AFM procedure.
If electrical power cannot be restored, consider which equipment is essential for the remainder of the flight. Unnecessary electrical loads may need to be reduced while you evaluate weather, airspace, communications, navigation requirements, and the nearest suitable airport.
The battery may now represent a limited source of remaining electrical power, making time an important consideration.
Pitot-Static and Instrument Failures
A blocked pitot tube or static source can produce misleading flight instrument indications.
Depending on what is blocked, affected instruments may include:
- Airspeed indicator
- Altimeter
- Vertical speed indicator
The important skill is recognizing when the indications no longer agree with what the airplane is actually doing.
Use known pitch and power relationships, other instruments, outside visual references, and alternate static sources when installed and appropriate.
Do not allow one unreliable instrument to convince you to make control inputs that contradict the rest of the airplane.
Landing Gear and Flap Malfunctions
A landing gear or flap malfunction requires deliberate troubleshooting and careful planning.
For landing gear abnormalities, consider:
- Gear position indications
- Circuit breakers and electrical indications
- Emergency extension procedures
- Visual confirmation when available
- Aircraft-specific limitations
- Appropriate landing technique
Flap malfunctions may require a no-flap, partial-flap, or asymmetric-flap procedure, depending on the aircraft and failure.
Expect changes in approach speed, landing distance, pitch attitude, control forces, and go-around performance.
Always use the applicable POH/AFM procedure.
Avionics and Navigation Failures
Modern avionics are useful, but they should never become a single point of failure for the pilot.
If GPS, a primary display, autopilot, communication radio, or other electronic equipment fails:
- Maintain aircraft control.
- Identify what capability has actually been lost.
- Use available backup equipment.
- Reestablish navigation and situational awareness.
- Determine whether continuing the flight is appropriate.
A failed display should not result in a loss of the pilot’s mental picture of the flight.
Commercial pilots should always know where they are, where they are going, and what resources remain available.
Circuit Breakers Require Caution
A tripped circuit breaker can indicate an electrical problem that should not simply be reset repeatedly.
Follow the manufacturer’s guidance regarding circuit breaker use.
Repeatedly resetting a breaker without understanding why it tripped can restore power to a malfunctioning component and potentially create a more serious electrical or fire hazard.
Treat the tripped breaker as information about the system, not merely an inconvenience.
Troubleshoot Without Losing Control
Troubleshooting can easily become a distraction.
Use the familiar priority:
Aviate → Navigate → Communicate
Maintain aircraft control first. Determine where the airplane is going and whether a diversion is necessary. Then communicate with ATC and complete additional troubleshooting as workload permits.
If the malfunction is time-critical, use memory items when applicable and follow with the checklist.
Do not spend several minutes troubleshooting a system when the safer decision is to land the airplane.
Practical Scenario: Alternator Failure
You are flying cross-country when the low-voltage warning illuminates and the electrical system indicates the alternator is no longer supplying power.
The airplane is still flying normally, so your first responsibility remains aircraft control.
You confirm the abnormal indications and complete the applicable POH/AFM procedure. The alternator does not return online.
Now the problem becomes a decision-making exercise.
You evaluate:
- Remaining battery power
- Day versus night conditions
- Weather
- Airspace
- Navigation requirements
- Communication needs
- Nearby suitable airports
Rather than continuing toward the original destination and hoping the battery lasts, you reduce unnecessary electrical loads and begin planning a diversion to a suitable airport while reliable electrical power remains available.
The important decision was not simply identifying an alternator failure.
It was recognizing that a manageable malfunction could become a much larger problem if the flight continued unnecessarily.
When Should You Land?
Not every malfunction requires an immediate landing, but every malfunction should trigger a reassessment of the flight.
Ask:
What capability have I lost?
What could fail next?
How will this affect the flight if conditions deteriorate?
Is continuing still the safest option?
A commercial pilot should avoid allowing get-there-itis or convenience to influence a decision involving a degrading aircraft system.
A precautionary landing made early is often preferable to an emergency landing made later.
Common Errors
Watch for:
- Poor understanding of aircraft systems
- Misidentifying the malfunction
- Fixating on one indication
- Failure to cross-check other instruments
- Improper checklist use
- Excessive troubleshooting
- Repeatedly resetting circuit breakers
- Failure to use backup equipment
- Loss of situational awareness
- Delaying a diversion or landing
- Continuing flight with a deteriorating system without a clear plan
Troubleshooting should support safe decision-making—not distract from it.
What the DPE Is Looking For
Be prepared to discuss and demonstrate:
- Aircraft systems and normal operation
- Recognition of abnormal indications
- Electrical system failures
- Pitot-static and instrument malfunctions
- Landing gear or flap abnormalities, when applicable
- Avionics and navigation equipment failures
- Appropriate use of checklists
- Backup equipment and alternate procedures
- Circuit breaker considerations
- Diversion and landing decisions
- Workload and risk management
Expect scenario-based questions rather than simply being asked to list system components.
A DPE may present an abnormal indication and ask:
“What do you think has failed, how would you verify it, and what are you going to do about it?”
Your answer should demonstrate both systems knowledge and sound aeronautical decision-making.
Final Takeaway
Systems knowledge becomes valuable when something stops working.
Recognize abnormal indications, understand what they mean, cross-check the available information, use the appropriate POH/AFM procedure, and continually evaluate whether the airplane is still safe to continue.
Identify the problem, protect the airplane, and make the decision before the malfunction makes it for you.
That is the level of systems knowledge and judgment expected from a commercial pilot.
FAA References
- Commercial Pilot for Airplane Category Airman Certification Standards, FAA-S-ACS-7B
- Pilot’s Handbook of Aeronautical Knowledge, FAA-H-8083-25C
- Airplane Flying Handbook, FAA-H-8083-3C
- Aeronautical Information Manual (AIM)
- Aircraft-specific POH/AFM and emergency checklists
